Cone Winding Knitting Warping Machine Re-Coning Machine
Technical Parameters:
Suitable yarn number 18-98tex
Warp beam available breadth 1600mm 1800mm
Disk sheet diameter of warp beam 800mm 1000mm
Speed of making chlinders 0~130m/min
Length of making cylinders 20S yarn 3500 meters
Number of head in making cylinders 400-480 (user definded)
Operation monitor 5.5” touch screen
Input voltage 3x380V+10%
Installed capacity 3servo motors, 3KM of each
Complete appliance weight 7000kg
End Break Detecting: Infer-Red Stop Motion Sensor
Count of the yarn: 7S ~ 40S
Tension: 30 ~ 50 g/end
Cone size: 078mm X L100mm
